Marker Captions

Everything below can be changed without touching the animation. Hand the list to an agent, or edit the values at the bottom of the component file.

• Srt

  srt · string

  Paste an SRT or WebVTT file's text. When it has cues it replaces `words`, and the words inside each cue share its time in proportion to their length. Captions play for as long as the clip runs, 8 seconds by default, so a longer transcript stops where the clip ends: lengthen the clip in your project to show all of it.

• Words

  words · array

  Per-word timings in seconds, exactly as a transcription tool exports them. Used whenever `srt` is empty. Each caption appears on its first word's start time, not a frame later.

  now: 21 items

• Max words

  maxWords · number

  How many words share one screen. A screen also ends at a full stop, at a cue boundary and at any pause longer than 0.6 seconds, so a caption never runs across two sentences. Five reads as a line of notes; 2 or 3 suits fast vertical edits.

  now: 5

• Emphasis

  emphasis · array

  Words that get the highlighter, matched ignoring case and punctuation, so `$72,000` also matches `72000.` and `7%` matches `7`. Mark what a viewer should remember: figures, names, the one word the sentence turns on. Every occurrence is marked.

  now: 5 items

• Position

  position · "lower" | "center" | "upper"

  Where the caption sits. On a vertical 9:16 frame `lower` stays above the bottom 18%, where the platform draws its own text and buttons, and every position keeps out of the right-hand 12%, where the like and share column is. Use `upper` when your lower third is busy and `center` for a talking head with room in the middle.

  now: lower

• Marker color

  markerColor · "highlighter" | "accent"

  Which ink the marker uses. `highlighter` is the brand's second accent, yellow on notebook. `accent` is its main accent, red on notebook, laid down as the pink a red highlighter really leaves, because any colour is thinned toward paper until the type on it reads at 7:1 or better.

  now: highlighter

• Scale

  scale · number

  Type size. At 1 the line is 7.8% of the frame height on 16:9 and 8.8% of the width on 9:16, which reads on a phone held at arm's length. Long words shrink a screen to fit rather than run off the frame.

  now: 1

• Halo

  halo · number

  A soft paper-coloured glow around each letter, which keeps dark type readable over dark or busy footage. It fades out of a word as the marker covers it, since the marker is doing that job there. Set 0 for clean type over a plain page.

  now: 0.6

• Stage

  stage · boolean

  Draw the stand-in shot behind the captions: a spiral notebook with the formula worked out, a highlighter and a flat white on a desk, in soft focus. It is there so the demo shows the captions over a picture. Switch it off when you put this over your own video.

  now: true

• Ground

  ground · boolean

  Paint the brand's plain paper colour behind the captions when the stand-in is off. Off by default: with `stage` and `ground` both off the captions render on a transparent background, ready to drop over your own footage.

  now: false

• Brand

  brand · string

  Brand token id, one of the keys of BRANDS. Notebook is the cream page and yellow highlighter this style is drawn for.

  now: notebook
